Optimize your heavy-duty electrical switching operations with the world-class Schneider TeSys Power Contactor series. Covering a highly versatile current range from 6A up to 800 Amps, these three-phase contactors support flexible control circuits handling both 24V AC and 690V DC setups, making them the ultimate defense line against heavy industrial load spikes.
| Model Name/Number | TeSys D,G,K,E SERIES |
| Brand | Schneider |
| Voltage | 24VAC/ 690DC |
| Current | 6- 800 amp |
| Phase | Three Phase |
| Weight | 0.48Kg |
| Warranty | 18 Months |
| Iec Standards | CSA C22.2 No 14, EN 60947-4-1, EN 60947-5-1, IEC 60947-4-1, IEC 60947-5-1, UL 508 |
| Poles Description | 3P |
| Utilisation Category | AC-4, AC-1, AC-3 |
| Range | TeSys |
| Control Circuit Type | DC & AC standard |
| Control Circuit Voltage | 24 VDC & 230VAC , 415VAC , 48VAC , 24VAC , 110VAC |
| [Uimp] Rated Impulse Withstand Voltage | 6 kV conforming to IEC 60947 |
| Average Impedance | 2.5 mOhm - Ith 25 A 50 Hz for power circuit |
| Mechanical Durability | 30 Mcycles |
| Coil Technology | Built-in Bidirectional Peak limiting Diode Suppressor |
| Power Pole Contact Composition | 3 NO |
| Dimension(WxHxD) | 45mm x 77mm x 95mm |
| Compatibility Code | LC1D |
| Contactor | Motor control , Resistive load |
| Power Dissipation per Pole | 1.56 W AC-1 0.2 W AC-3 |
| Maximum Operating Rate | 3600 cyc/h 60 degrees C |
| Motor Starter Type | Direct on-line contactor |
| Mounting Support | Plate, Rail |
| Inrush Power in W | 5.4 W (at 20 C) |
| IP Degree of Protection | IP20 front face conforming to IEC 60529 |
| Time Constant | 28 ms |
